Slider

Sliders allow users to select a value from a fixed set of options.

This component is a forked implementation of react-native-slider.

Usage

import { Slider } from 'react-native-elements';
import { Animated } from 'react-native';

<View style={{ flex: 1, alignItems: 'stretch', justifyContent: 'center' }}>
  <Slider
    value={this.state.value}
    onValueChange={(value) => this.setState({ value })}
  />
  <Text>Value: {this.state.value}</Text>
</View>;

// Replace Thumb with custom image
<View style={{ flex: 1, alignItems: 'stretch', justifyContent: 'center' }}>
  <Slider
    value={this.state.value}
    onValueChange={(value) => this.setState({ value })}
    thumbStyle={{ height: 40, width: 40, backgroundColor: 'transparent' }}
    thumbProps={{
      Component: Animated.Image,
      source: {
        uri: 'https://s3.amazonaws.com/uifaces/faces/twitter/ladylexy/128.jpg',
      },
    }}
  />
  <Text>Value: {this.state.value}</Text>
</View>;

// Set Custom Children inside thumb
<View style={{ flex: 1, alignItems: 'stretch', justifyContent: 'center' }}>
  <Slider
    value={value}
    onValueChange={setValue}
    maximumValue={50}
    minimumValue={20}
    step={1}
    trackStyle={{ height: 10, backgroundColor: 'transparent' }}
    thumbStyle={{ height: 20, width: 20, backgroundColor: 'transparent' }}
    thumbProps={{
      children: (
        <Icon
          name="heartbeat"
          type="font-awesome"
          size={20}
          reverse
          containerStyle={{ bottom: 20, right: 20 }}
          color="#f50"
        />
      ),
    }}
  />
  <Text>Value: {this.state.value}</Text>
</View>;

---

Props

• allowTouchTrack
• animateTransitions
• animationConfig
• animationType
• debugTouchArea
• disabled
• maximumTrackTintColor
• maximumValue
• minimumTrackTintColor
• minimumValue
• onSlidingComplete
• onSlidingStart
• onValueChange
• orientation
• step
• style
• thumbProps
• thumbStyle
• thumbTintColor
• thumbTouchSize
• trackStyle
• value

---

Reference

allowTouchTrack

If true, thumb will respond and jump to any touch along the track.

Type	Default	Optional
boolean	false	Yes

---

animateTransitions

Set to true if you want to use the default 'spring' animation

Type	Default	Optional
bool	false	Yes

---

animationConfig

Used to configure the animation parameters. These are the same parameters in the Animated library.

Type	Default	Optional
object	undefined	Yes

---

animationType

Set to 'spring' or 'timing' to use one of those two types of animations with the default animation properties.

Type	Default	Optional
string	'timing'	Yes

---

debugTouchArea

Set this to true to visually see the thumb touch rect in green.

Type	Default	Optional
bool	false	Yes

---

disabled

If true the user won't be able to move the slider

Type	Default	Optional
bool	false	Yes

---

maximumTrackTintColor

The color used for the track to the right of the button

Type	Default	Optional
string	'#b3b3b3'	Yes

---

maximumValue

Initial maximum value of the slider

Type	Default	Optional
number	1	Yes

---

minimumTrackTintColor

The color used for the track to the left of the button

Type	Default	Optional
string	'#3f3f3f'	Yes

---

minimumValue

Initial minimum value of the slider

Type	Default	Optional
number	0	Yes

---

onSlidingComplete

Callback called when the user finishes changing the value (e.g. when the slider is released)

Type	Default	Optional
function		Yes

---

onSlidingStart

Callback called when the user starts changing the value (e.g. when the slider is pressed)

Type	Default	Optional
function		Yes

---

onValueChange

Callback continuously called while the user is dragging the slider

Type	Default	Optional
function		Yes

---

orientation

Set the orientation of the slider.

Type	Default	Optional
string	'horizontal'	Yes

---

step

Step value of the slider. The value should be between 0 and maximumValue - minimumValue)

Type	Default	Optional
number	0	Yes

---

style

The style applied to the slider container

Type	Default	Optional
style		Yes

---

thumbProps

The props applied to the thumb. Uses Component prop which can accept Animated components.

Type	Default	Optional
object		Yes

---

thumbStyle

The style applied to the thumb

Type	Default	Optional
style		Yes

---

thumbTintColor

The color used for the thumb

Type	Default	Optional
string	'#343434'	Yes

---

thumbTouchSize

The size of the touch area that allows moving the thumb. The touch area has the same center as the visible thumb. This allows to have a visually small thumb while still allowing the user to move it easily.

Type	Default	Optional
object	{width: 40, height: 40}	Yes

---

trackStyle

The style applied to the track

Type	Default	Optional
style		Yes

---

value

Initial value of the slider

Type	Default	Optional
number	0	Yes

---
